Mapping and configuration
> Color in the pdf Color in Viasat GUI Number in Viasat GUI
> RED BLUE 1
> GREEN ORANGE 2
> BLUE PURPLE 3
> YELLOW GREEN 4
> Beam number Beam color Symbol rate Center frequency
Polarization
> 1 Blue 50 19.73125 RHCP
> 2 Orange 50 19.99375 RHCP
> 3 Purple 50 20.11875 LHCP
> 4 Green 50 19.85625 LHCP
