Annex A
Pre - programmed channels
LENNAHC-BUSYCNEUQERFLENNAHC
1 446.00625 N130DzHM = DCS code 04
2 446.01875 N150DzHM = DCS code 08
3 446.03125 N270DzHM = DCS code 1Ϯ
4 446.04375 N511DzHM = DCS code ϭϲ
5 446.05625 N231DzHM = DCS code ϮϬ
6 446.06875 N551DzHM = DCS code 2ϰ
7 446.08125 N271DzHM = DCS code Ϯϴ
8 446.09375 N622DzHM = DCS code 3Ϯ
9 446.00625 MHz -
10 446.01875 MHz -
11 446.03125 MHz -
12 446.04375 MHz -
13 446.05625 MHz -
14 446.06875 MHz -
15 446.08125 MHz -
16 446.09375 MHz -
Annex B
Speaker / microphone connection diagram
Annex C
Technical specifications
Frequency range : 446.00625 … 446.09375 MHz
Channel spacing : 12.5 KHz
Channels : 16
Maximum RF output power : 0.5 W
Modulaon : FM – F3E
Antenna type : Fixed
Audio output power : <=500mW
Baery type : 3.8V – 2000mAh (Li-ion)
Operaon temperature : -20 °C … +55°C
IP-standard 45PI:
Dimensions : 120 x 55 x 27 mm (without antenna)
Weight : 165 g (including baery, antenna)
