1/4 mi Test Results - record the elapsed time for a vehicle to travel
a certain distance (60 ft, 330 ft, 1/8 mi, 1000 ft, 1/4 mi), and the
instantaneous speed at each point (see Figure 4-18 and Figure 4-21).
0-60 MPH Test Results - record the elapsed time for a vehicle to
accelerate from 0 to 60 miles per hour (see Figure 4-19). The values
for the start and end speeds can be changed if desired.
Speed Test Results - record the elapsed time for a vehicle to
accelerate to a specic speed (see Figure 4-21).
4.4 Maintenance
This function provides you with 8 maintenance services including
Oil Reset, Throttle Adaptation, Electronic Parking Brake (EPB) Reset,
Steering Angle Reset, Diesel Particulate Filter (DPF) Regeneration,
Anti-lock Braking System (ABS) Bleeding, Battery Management
System (BMS) Resets and Airbag Reset.
4.4.1 Services Overview
Oil Reset
This function allows you to reset the oil service lamp for the engine
oil life system, which calculates an optimal oil life change interval
depending on the vehicle driving conditions and weather events. Oil
reset is required every time the engine oil is changed.
EPB Reset
This function helps you replace and reset the brake pads.
It needs to be performed in the following cases:
• After the brake pads and brake pad wear sensor are replaced;
• When the brake pad warning light is on;
• After a short circuit in the brake pad sensor is xed;
• After the servo motor is replaced.
Steering Angle Reset
If the steering angle sensor is replaced, or the steering angle is
inaccurate or not centered, the steering angle reset function needs
to be performed to nd the relative zero position. With this position
as a reference, the ECU can then calculate the exact angle for left
and right steering.
