Topdon Topscan - 1. Indicators; 2. OBD-II 16 Pin Connector; 3. USB Type-C Port

50 pages

To Next Page

To Previous Page

1. Indicators

2. OBD-II 16 Pin Connector

Connects the TopScan to vehicle's DLC.

3. USB Type-C Port

Connects the TopScan to a computer for updates.

Solid Blue: Bluetooth

connected

Solid Red: power on

Flashing Green:

communicating with the

vehicle

Bluetooth Connection

Indicator

Power Indicator

Communication

Indicator
