Drawing 10148 REV 0 24-11-15
Installation Instructions for TEC Pool Dosing Equipment
This equipment is only to be installed by a person qualified in electrical and
chemical plumbing systems
Technical Data TEC4000 Control System
Dimensions 365mm wide x 650mm tall x 110mm deep
Power Requirement 240 VAC single phase 50 Hz.
Power Consumption 20 watts (Excluding Feeders)
Operating Temperature 0 - 50 degrees centigrade
Enclosure Metal IP54
Front control panel Touch Screen behind polyester membrane
Display Graphic LCD ¼ VGA 120mm wide x 90mm high
Chlorine sensor Amperometric 3 electrode system
Measuring range 0 - 40 mg/l
pH sensor Glass with internal reference
Measuring range 0-14 pH
Redox +/- 2v
Outputs Chemical feeders 3 x 240 VAC 2amps switched
External Alarm Voltage free no/nc
USB port
RS485 data port
WIFI
BMS output 0-10v pH, chlorine and redox
Timed 240 VAC 2 amps electric agitator
Timed 240 VAC 2 amps flocculent
Energy control system
Real time clock
Inputs 3 analogue
2 digital flow sensor
Touch Screen Display
Programmable input
To Next Page
