GB - USA Parts list
Part # Part name Material, dimensions Loose In bag Spare part
building instruction 1 -
1A
fuselage front part fibreglass 1 -
02055E-1
1B
fuselage tube fibreglass 1 -
02056-1B
1-1
motor mount fibreglass - 1
02040-1C
1-2
servo tray plywood 4 mm - 1
020STS-1-2
1-3
air hole cover ABS - 1
02073-1.1
2
wing balsa assembly 2 -
2-1
aileron balsa 2 -
24
wing joiner steel Ø5 x 180 mm - 1
02055TPW -24
2-2
wing fixing screw screw M 4 x 20 mm - 2
1310
2-21
centering pin fibreglass Ø3 x 50 mm - 2
6BI21828
2-25
centering pin fibreglass Ø2 x 22 mm - 1
6BI21827
2-3
nut Al M4 - 2
1022 AL
2-31
nut mount plywood 3 x 20 x 35 mm - 1
020NM02
2-4
servo mount polyurethan 9mm - 4
5025
2-41
wing servo cover ABS plastic - 2
50191
2-5
aileron-flap pushrod piano wire Ø 1,7 M2 - 2
166240
2-7
clevis Micro plastic L=17, pin Ø1mm - 2
2101
2-8
aileron horn fibreglass plate 1 mm - 2
50551
3
horizontal stabilazer balsa 1 -
02055-3ARF, 02055-3ARC
bowden Ø2 mm L=790mm,
piano wire Ø0,8 mm L= 870mm
3-6
threaded coupler brass, M2- Ø1/Ø3 - 1
2014 BR
3-7
clevis Micro plastic L=17, pin Ø1mm - 1
2101
3-8
horn fibreglass plate 1 mm - 1
5056
4
vertical tail balsa 1 -
02055-4ARF, 02055-4ARC
4A
vertical tail mount plywood 4 mm - 1
02055-4A
bowden Ø2 mm L=790mm,
piano wire Ø0,8 mm L= 870mm
4-6
threaded coupler brass, M2- Ø1/Ø3 - 1
2014 BR
4-7
clevis Micro plastic L=17, pin Ø1mm - 1
2101
4-8
horn fibreglass plate 1 mm - 1
5056
6
canopy fibreglass 1 -
02055-6
6-4
canopy fixing screw Ø2,9x6,5 mm - 1
202965
7
stickers sets 1 -
02055-7
11
pinned hinge 25x20 - 1
3DK12402
02055TPW -2ARF
02055TPW -2ARC
SET2108
SET2108
3-5
link
1
-
4-5
vertical tail link
1
-
Item No.www.t opmodelcz.com
servo Dymond D60 2 for ailerons 020D1816
HS-65HB 2 for elevat or & rudder 1HI3177
controller SPIN 33 PRO 1 1RC23202
spinner Alu precision spinner 30/3,17/8 1 0201503
propeller CAMcarbon 9x6" 1 723401
battery 3S - 1,5-2,1Ah 1
