TOPRO Troja Walker - Height Adjustment with Memory Function

Height adjustment with memory function
1
You have the opportunity to set the height of the
handles as a standard, so you automatically can
find the height you once set. This can be
necessary when the rollator is being transported
or stored as compact as possible.
Decide the height of the handles. Count visible
holes (4) on the back of the handle profile (5).
Screw the lock wheel out and pull the handle
p
rofile out of the frame. The fastened part (1) is
now following the handle profile. Move the
fastened part so there are equal holes as earlier
counted. Fasten the memory chip (2) on the
handle profile (5) in the first hole under the
fasten part. Push the fasten part (1) until it is
locked. Screw the locking wheel (3) half in, and
p
ull the handle profiles until they stop, then
fasten the lock wheel (3). From now on when the
handle profiles are pulled up or pushed down
they will stay in the remembered position.
4+ 5
3
2
26
