LI-959(A)
EXAMPLE:
To change time delay from 5 min to 10 min:
1. START Press the button 5 times.
a. The LED is now on.
2. CHOOSE Press the button the number of times for the mode you wish to change.
a. Press the button 1 time for Function 1.
b. The sensor now flashes twice, pauses, flashes twice, pauses, etc.
(This shows the current program)
3. CHANGE Press the button 1 time.
a. The sensor now flashes once, pauses, flashes once, pauses, etc.
(This shows the new program setting)
4. SAVE Now press and hold the button for 5 seconds.
a. The LED is now on
b. Now press the button 5 times
c. The time delay is changed to 5 minutes
NOTE: To exit programming without making a change, if no button is pressed for 30 sec the
sensor will return to run mode with the last settings that were locked in.
FOUR & OUT THE DOOR SETTINGS CHANGE
To change a program feature:
PREP: Review the function to see the function number, current setting and new setting that is
to be entered.
1. START program mode:
a. Press the button 5 times consecutively. (The LED flashes with each press)
NOTE: After the 5th button press the LED will stay on. The sensor is now in Program Mode.
2. CHOOSE the function:
a. Press the button "X" number of times to enter a function to change. (The LED
flashes with each press)
NOTE: When the button presses stop the sensor will then flash back the current setting for
that function. (The sensor will do this 10 times and then go back to run mode if nothing is
processed with prior settings)
3. CHANGE Function:
a. Press the button the number of times for the new setting. (The LED flashes
with each press)
NOTE: When the button presses stop, the sensor will then flash back the new setting for
that function. (The sensor will do this 10 times and then go back to run mode if nothing is
pressed and the new setting will not be saved)
4. SAVE Setting
a. Press and hold the button until the LED stays on, then release the button.
b. Press the button 5 times to lock in the setting. (The LED flashes with each press)
After the 5th press the sensor will go back to run mode with the new setting active.
FOR TECHNICAL SUPPORT: techsupport@nsiindustries.com 888.500.4598
INSTALLATION INSTRUCTIONS
PUSH BUTTON FUNCTION CHART
Function 1 - Time Delay
1. 10 min*
2. 5 min
3. 15 min
4. 20 min
5. 25 min
6. 30 min
Function 2 - Ultrasonic Coverage
(For WOS-MN2T Only)
1. Large Area*
2. Medium Area
3. Small Area
Function 3 - Photocell Set Point Ones
Digit
(Not WOS-SN)
1. Disabled*
2. 2 fc
3. 3 fc
4. 4 fc
5. 5 fc
6. 6 fc
7. 7 fc
8. 8 fc
9. 9 fc
10. 0 fc
Function 4 - Photocell Set Point Tens
Digit
(Not WOS-SN)
1. 0 fc*
2. 10 fc
3. 20 fc
4. 30 fc
5. 40 fc
6. 50 fc
7. 60 fc
8. 70 fc
9. 80 fc
10. 90 fc
11. 100 fc
12. 200 fc
Function 5 - PIR Coverage
1. Large Area*
2. Small Area
Function 6 - Mode
1. Auto On/Off*
2. Manual On/Auto Off (Vacancy)
3. Walk Through
4. Test Mode (if left in test mode for
30 min, revert to default settings)
Function 7 - Push Button Disable
1. Button Active*
2. Button Disabled
Function 8 - 100 Hour Burn-In
1. Disabled *
2. Enabled
Function 9 - Warning Flash before shut off
1. Disabled*
2. Enabled
Function 10 - Initial Turn On Sensor Trigger
(For WOS-MN2T Only)
1. PIR and Ultrasound*
2. Ultrasound Only
3. PIR Only
Function 11 - Maintain On Sensor Trigger
(For WOS-MN2T Only)
1. Either PIR or Ultrasound*
2. Ultrasound Only
3. PIR Only
Function 15 - Factory Defaults
1. Disabled*
2. Enabled
*Default Settings
