HEADMASTER 4000 PARTS LIST
Vacuum Head Assembly
(All Models)
Tank Assembly
(94190 & 94191)
ITEM PART
NO
QTY DESCRIPTION ITEM PART
NO
QTY DESCRIPTION
1 1604 2 Nut-Hex.(Machine Screw) #10-32 1 64 2 Screw-Oval Hd 1/4-20 x 3/4"(Nick)
2 1713 1 Washer-Lock(H/S)#10 2 1574 4 Washer-Lock (H/S) 1/4"
*
2563
1
Plug-Power Cable(Male) 230V(3-Pr)
3 1978 4(**3) Screw-Rnd Hd 1/4-20 x 1-1/2"
3 2961 1 Strain Relief Bushing(SR 6L-1) **4 1979 1 Screw-Rnd Hd 1/4-20 x 2"
4 3261 1 Screw-TCT(F)Pan Hd #10-32 x 3/8" 5 2663 4(**2) Ring-Retaining 1/2"(External)
5 10671 1 Gasket-Vac.Motor 6 5427 2 Screw-Rnd Hd 1/4-20 x 5/8"
6 10894 1 Nut-Hex.Lock(I/T)#10-24 7 14867 2 Wheel-8"
7 11007 2 Washer-Lock(I/T)#10 8 16089 1 Plug-Drain Hose
8 11390 20 Screw-Pan Head #10-16 x 5/8" 9 16091 1 Clamp-Hose(Screw)1-1/4"-2"(Lin)
9 12896 1 Screw-Round Head #10-32 x 5/8" 10 17273 1 Bracket-Drain Hose Retaining
10 14800 1 Motor-Vacuum, Bypass, P/D 115V 11 17507 2 Nut-Acorn 1/4-20(SS)
*
17425
1
Motor-Vacuum, Bypass, P/D 230V
12 17784 2 Plug-Tube, 18 Ga. X 1"OD
11 15139 2 Terminal-Q.D.Female 1/4" x 13 18054 1 Handle-Tank(Hm-4000)
12 17342 1 Switch-Rockr,DPST.20A/125-1/2HP 14 18060 1 Tank-Vacuum, 21 Gallon
13 17351 1 Sleeve-Motor Exhaust Vent 15 18063 1 Weldment-Axle
14 17353 2 Spring-Tank Latch 16 18066 2 Caster-3"Dia.
15 17354 2 Bracket-Tank Latch Mtg.(L/H) 17 18071 1 Hose-Tank Drain
16 17356 2 Bracket-Tank Latch Mtg.(R/H) 18 18563 1 Nozzle-Drain Hose
17 17357 2 Latch-Tank(Vac.Head) 19 19373 2 Washer-Plain 1/2"
18 17368 1 Intake-Vacuum Head 20 19409 1 Assembly-Tank Drain Fitting
19 17376 1 Nut-Hex.Lock(Plastic) #10-24
20 17377 1 Panel-Motor Exhaust Vent
21 17378 1 Lead-18 Ga. X 11" Green
O
p
tions & Accessories
22 17392 1 Clamp-Cable(CCH 5/16")
23 17398 1 Intake Hose Retainer Assembly * 90654 1 Attachment Set-(1-1/2")T-Lite(Wet/Dry)
24 17405 1 Gasket-Tank Includes:
25 17419 1 Screw-Rnd Hd (Nyl) #10-24 x 1/2" 90286 4' Aluminum Wand
26 17451 7 Screw-Pan Hd #10-24 x 7/16"(BO) 90286 10' Poly. Hose
27 17472 1 Assembly-Intake Plate 90640 14" Squeegee Tool
28 17562 1 Electrical Panel Closure 90693 14" Carpet Tool
29 17816 1 Baffle 90004 15" Crevice Tool
30 17847 1 Plate-Motor Mounting 90380 3" Dia. Dusting Tool
31 17848 4 Screw-Truss Hd #10-24 x 1/2"(SS)
32 18515 1 Float Cage * 90050 1 Filter-Hospital(3/PK) HM Vacs
33 18538 4 Retainer-Float Cage
34 19410 1 Gasket-Vac.Motor(Upper)
35 19411 1 Gasket-Vac.Motor(Lower)
36 19412 1 Assembly-Power Cord (115V)
37 19413 1 Assembly-Float
38 19414 1 Assembly-Vac.Head Cover
39 19415 1 Assembly-Vac Head Base
40 19416 1 Assembly-Elect.Panel
41 19417 1 Assembly-Intake Elbow
42 98585 1 Filter-Foam(12PK)Vac.Mtr Intake
43 98609 1 Filter-Cloth Bag (Wet)
* 98766 1 Filter-Cloth Bag (Dry)
* Not Shown
