Latitude Elbow Prosthesis
Latitude Elbow Prosthesis Surgical Technique UCLT101
PRECISION INSTRUM
3. PRECISION INSTRUMENTATION
Trochlear cutting guides
Humeral trial
components
Ulnar cutting guides
Humeral rasps
Anatomical spools
Flexion-extention
axis drilling guide
Capitellum cutting guides
Ulnar diaphysis
drill guides
Bell saws
Ulnar rasps
The Latitude
®
Elbow instruments bring precision and reproducibility to elbow arthroplasty in the setting
where there has been some preservation of normal anatomy.
The instruments are designed to offer a reproducible step-by-step procedure. Each jig uses anatomic landmarks
to insure replication of the natural anatomy. The flexion-extension axis is easily determined. The humeral, radial
and ulnar surgical steps are based on this reference point.
