17
BEFORE OPERATING
CAUTION
If engine has been running, pressurized
hot coolant can escape when radiator
cap is removed and cause burns. Only
open radiator cap when engine is cold.
Figure 32
1. Access panel
2. Radiator
3. Oil cooler
1
3
2
2. Check level of coolant in expansion tank. With a
cold engine, coolant level should be midway (approx)
between the marks on side of tank.
Figure 33
1. Expansion tank
1
3. If coolant level is low, remove expansion tank cap
and replenish the system. DO NOT OVERFILL.
4. Install expansion tank cap.
CHECK HYDRAULIC SYSTEM FLUID
(Fig. 34)
The hydraulic system driving the reels is designed to
operate on anti-wear hydraulic fluid. The machines
reservoir is filled at the factory with approximately 3.5
gallons of DTE 15M hydraulic fluid. Check level of
hydraulic fluid before engine is first started and
daily thereafter.
IMPORTANT: Use only types of hydraulic fluids
specified. Other fluids could cause system
damage.
Group 1 Hydraulic Fluid (Moderate climate-
average duty)
Note: The fluids within this group are interchangeable.
ISO VG 46/68 multiviscosity antiwear
hydraulic fluid
Mobil DTE 15M
Amoco Rykon Premium ISO 46
Castrol AWH 46
Conoco Hydroclear AW MV46
Gulf Harmony HVI 46 AW
Kendall Hyken Golden MV SAE 5W20
Pennzbell AWX MV46
Phillips Magnus A KV 5W20
Shell Tellus T 46
Sunoco Sun Hyd. Oil 2105
Texaco Rando HDZ 46
Universal Tractor Hydraulic Fluid
Mobil Mobilfluid 424
Amoco 1000 Fluid
Chevron Tractor Hydraulic Fluid
Conoco Hydroclear Powertran
Esso Hydraul
Gulf Universal Tractor Fluid
Kendall Hyken 052
Marathon Marafluid Super HT
Pennzoil Hydratrans
Phillips HG Fluid
Shell Donax TD
76 Lubricants Hydraulic/Tractor Fluid
Sunoco TH Fluid
Texaco TDH
Group 2 Hydraulic Fluid (Hot Climate- Heavy Duty)
Note: The fluids within this group are interchangeable.
ISO VG 68 antiwear hydraulic fluid
Mobil DTE 26
Amoco Rykon AW No. 68
Castrol AWS 68
Chevron Hydraulic Oil AW ISO 68
Conoco Hydroclear AW 68
Exxon Nuto H 68
Gulf Harmony 68AW
Kendall Four Seasons AW 68
Marathon ISO 68
Pennzbell AW Hydraulic Oil 68
Phillips Magnus A ISO 68
Shell Tellus 68
76 Lubricants AW 68
Sunoco SunVis 868
Texaco Rando HD 68
