Chapter 3
Kohler Engine
Table of Contents
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 1
ADJUSTMENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Carburetor Adjustments
. . . . . . . . . . . . . . . . . . . . 2
KOHLER MAGNUM ENGINE SERVICE MANUAL
Specifications
Item Specification
Make/Designation Kohler M16S
Air cooled, single cylinder, gasoline, horizontal shaft
Weight (approximate) 129 lb.
Crankcase Oil Capacity 5.25 pints
Oil API Classification SF or SG
Above +32° F (0° C) SAE 30W recommended
or SAE 10W-30 or 10W-40 as a substitute
Below +32° F (0° C) SAE 5W-20 or 5W-30 recommended
or SAE 10W-30 or 10W-40 as a substitute
Fuel Unleaded Regular Gasoline
High RPM Setting (no load) 3600 ± 100 RPM
Low RPM Setting (no load) 1200 ± 100 RPM
Reelmaster
®
216/216-D Page 3 - 1 Specifications
