Chapter 4

Perkins Diesel Engine

Table of Contents

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 1

ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . 2

Throttle Linkage Adjustment . . . . . . . . . . . . . . . . 3

Bleeding the Fuel System . . . . . . . . . . . . . . . . . . 2

PERKINS 100 SERIES WORKSHOP MANUAL

Specifications

Item Specification

Make/Designation Perkins, vertical in-line,

3 cylinder, liquid cooled Diesel

Type 103-06 KB70238

Firing Order 1 - 2 - 3

Injection Timing 27° - 29° BTDC

Weight (approximate) 141 lb. (64 Kg)

Crankcase Oil Capacity 3.0 liter (3.2 U.S. qt.) including filter

Oil API CD

SAE 10W-30

Fuel No. 2 Diesel

High RPM Setting (no load) 3200 ± 100 RPM

Low RPM Setting (no load) 1250 ± 50 RPM

Reelmaster

216/216-D Page 4 - 1 Specifications
