RearWheelGearBox(Optional3WD)

g293226

Figure127

1.Rearwheelgearboxandmotorassembly

7.Flangenut(2each)

2.Rearwheelhubassembly

8.Spacer(2each)

3.Venthose9.Harnessbracket

4.Venttting10.Flatwasher(2each)

5.O-ring11.Capscrew(2each)

6.Flangeheadscrew(4each)

RemovingandInstallingtheRearWheelGearBox

RefertoFigure127forthisprocedure.

1.Removetherearwheel;refertoRemovingandInstallingtheWheels(page

6–9).

2.Removethelowerpluganddraintheoilfromthegearbox.Inspecttheplug

O-ringandreplaceasnecessary.

3.Unplugthe48Vbattery;referto48VBatteryDisconnect(page5–9).

4.Locatethe3WDtractionmotorconnectionstothemachinewireharnessand

disconnectthe2connectors.Checkthemotorandtheharnessconnectorfor

damageorcorrosionandcleanorrepairasnecessary.

5.Removetherearwheelhubfromthe3WDtractionmotor;refertoRear

WheelHub(Optional3WD)(page6–17).

6.Removetheventhoseandttingfromthemotorandgearboxassembly.

InspecttheventttingO-ringandreplaceasnecessary.

7.Removethe4fastenerssecuringthegearboxtothecasterforkandremove

themotorandgearboxassembly.

8.Installthemotorandgearboxassemblyinreverseorder.

9.Fillthegearboxwithapproximately1,200cc(40oz)of80W-90gearoil(to

thebottomofthelevelplug)beforereturningthemachinetoservice.

Greensmaster®eTriFlex3360and3370

Page6–19

Chassis:ServiceandRepairs

19239SLRevB
