Toro Greensmaster 3250-D - Product Overview; Controls Description; Brake Burnishing Procedure

g234996
Figure17
1.CEproductionyeardecal3.Serialplate
2.CEmarkdecal
•ApplytheCEproductionyeardecalnexttotheCE
markdecal(Figure17).
14
BurnishingtheBrakes
NoPartsRequired
Procedure
Burnishthebrakes;refertoBurnishingtheBrakes
(page42).
ProductOverview
Controls
TractionPedal
Thetractionpedal(Figure18)has3functions:
tomakethemachinemoveforward,tomoveit
backward,andtostopthemachine.Pressthetop
ofthepedaltomoveforwardandthebottomofthe
pedaltomovebackwardortoassistinstoppingwhen
movingforward.Also,allowthepedaltomovetothe
NEUTRALpositiontostopthemachine.Donotrestthe
heelofyourfootonreversewhenoperatingforward
(Figure19).
g008430
Figure18
1.Tractionpedal3.Parking-braketab
2.Brakepedal
g005105
Figure19
BrakePedal
Pressthebrakepedal(Figure18)tostopthemachine
byactuatingthefront-wheelbrakes.
18
