17
RAGE AMPLIFIER SPECIFICATION CHART
MODEL MRX2 MRX4 MR2
Description 2ch 4ch Mono
4 Ohm RMS Power (Watt) 2x150 4x80 1x230
2 Ohm RMS Power (Watt) 2x250 4x130 1x320
1 Ohm RMS Power (Watt) N/A N/A 1x500
4 Ohm Bridged Power (Watt) 1x500 2x260 N/A
Peak Music Power (Watt) 2x250 4x130 1x600
THD @ RMS Power <0.05% <0.05% <0.05%
Freqquency Response 10Hz-40kHz 10Hz-40kHz 10Hz-220Hz
S/N Ratio (EIA Rated) >100dB >100dB >100dB
Input Sensitivity 200mV-10V 200mV-10V 200mV-10V
Crossover Slope 12dB
LPF/HPF
20Hz-300Hz/ 200-3kHz
20Hz-300Hz 50Hz-250Hz
Bass EQ (ON/OFF) N/A N/A OFF-12DB
Fuses/ ATC Style (Optional) 30A 40A 40A
Current Drawn @ Max Power 40A 50A 50A
Dimension (1.69" H x 3.07" W)
Dimension (43mm H x 78mm W)
Power output @ 14.4VDC Input
12dB (REAR CHANNEL)
5.75"
146mm
5.75"
146mm
5.75"
146mm
