Toro Sand Pro 2040Z - Installing Attachments and Weights

1
RemovingtheShippingBoard
NoPartsRequired
Procedure
Beforeyoucaninstallanattachmentonthemachine,you
mustremovetheshippingboard.
1.Removethenuts,bolts,andwasherssecuringthe
shippingboardtotherearofthemachine(Figure3).
G023667
Figure3
2.Discardthefastenersandtheshippingboard.
2
InstallinganAttachment
Partsneededforthisprocedure:
–
Attachmentandrelatedparts(soldseparately)
Procedure
WARNING
Ifyoudrivethemachinewithoutanattachment
installed,itcantipoverandinjuresomeoneor
damageproperty.
Drivethemachineonlyifthereisanapproved
attachmentinstalled.
RefertotheattachmentInstallationInstructionsforinformation
oninstallingtheattachment.
3
InstallingtheFrontWeights
Partsneededforthisprocedure:
–
Frontweights(asneededperattachment)
Procedure
ThismachinehasbeendesignedinaccordancewithANSI
B71.4-2012.However,whenyouinstallattachmentsonthe
machine,youmustaddadditionalweighttothemachine,as
specied,tocomplytothestandards.
Usethechartbelowtodeterminetheadditionalweight
required.Themachinecomeswith4weights.Each
attachmentcomeswiththenecessaryadditionalweights,if
required.
Attachment
Numberofweightsrequired
Flextoothrake4
Flextoothrakewithnishbrush
6
Naildrag6
Naildragwithnishdragmat
8
RefertoInstallingandRemovingtheWeights(page21).
