Toro Sand Pro 2040Z - Adjusting the Control-Handle Dampers; Adjusting the Neutral-Lock Resistance

AdjustingtheControl-Handle
Dampers
Youcanadjustthetopdamper-mountingbolttochangethe
control-handleresistance.
1.Toaccessthedamper-mountingbolts,removethebolts
thatsecurethestopplatestotheframe(Figure63).
1
2
G023557
Figure63
Left-handsideshown
1.Bolt(4)2.Stopplate
2.Removethelocknut,movethedamper-mountingbolt
tothedesiredposition,andinstallthelocknut.Referto
Figure64forthemountingoptions.
Note:Torquethelocknutto22.6N-m(16.7ft-lb).
Theboltmustprotrudepasttheendofthelocknut
whenitistight.
Figure64
Right-handsideshown
1.Locknut
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
3.Adjustthetracking;refertoAdjustingtheTracking
(page45).
AdjustingtheNeutral-Lock
Resistance
Ifyoupreferadifferentamountofside-to-sideresistancein
thecontrolhandleswhenyoumovethemintoandoutofthe
neutral-lockedposition,youcanadjustitasfollows:
1.Loosenthejamnut(Figure65).
Figure65
1.Flangednut2.Jamnut
2.Tightenorloosentheangednuttothedesiredfeel.
•Formoreresistance,tightentheangednut.
•Forlessresistance,loosentheangednut.
3.Tightenthejamnut.
4.Repeatthisprocedurefortheothercontrolhandle.
48
