Toro Z Master 77248 - Product Overview; Controls

ProductOverview
g336657
Figure6
1.Height-of-cutdeck-lift
pedal
7.Shockassembly
2.Height-of-cutpositions8.Seatbelt
3.Transportlock9.Fuelcap
4.Controls
10.Parking-brakelever
5.Motion-controllevers11.Mowerdeck
6.Rollbar
12.Casterwheel
Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.
ControlPanel
g271171
Figure7
1.Powerpoint5.Blade-controlswitch
(powertakeoff)
2.Chokecontrol
6.Keyswitch
3.Throttlecontrol
7.Lightswitch(formodels
withlightsonly)—optional
kitforothermodels
4.Hourmeter
KeySwitch
Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andSTART.Referto
StartingtheEngine(page27).
LightSwitch
ForModelswithLightsOnly
UsethelightswitchtoturnthelightstotheONposition
orOFFposition(Figure7).
ChokeControl
Usethechokecontroltostartacoldengine.
ThrottleControl
Thethrottlecontrolstheenginespeed,andithasa
continuous-variablesettingfromtheSLOWtoFAST
position(Figure7).
Blade-ControlSwitch(Power
Takeoff)
Theblade-controlswitch,representedbya
power-takeoff(PTO)symbol,engagesand
disengagespowertothemowerblades(Figure7).
14
