BreakinginaNewMachine
Newenginestaketimetodevelopfullpower.Mower
decksanddrivesystemshavehigherfrictionwhen
new,placingadditionalloadontheengine.Allow
40to50hoursofbreak-intimefornewmachinesto
developfullpowerandbestperformance.
Usingthe
Rollover-ProtectionSystem
(ROPS)
WARNING
Toavoidinjuryordeathfromrollover,keep
therollbarinthefullyraised,lockedposition
andusetheseatbelt.
Ensurethattheseatissecuredtothe
machine.
WARNING
Thereisnorolloverprotectionwhentheroll
barisinthedownposition.
•Lowertherollbaronlywhenabsolutely
necessary.
•Donotweartheseatbeltwhentherollbar
isinthedownposition.
•Driveslowlyandcarefully.
•Raisetherollbarassoonasclearance
permits.
•Checkcarefullyforoverheadclearances
(i.e.,branches,doorways,electricalwires)
beforedrivingunderanyobjectsanddo
notcontactthem.
LoweringtheRollBar
Important:Lowertherollbaronlywhen
absolutelynecessary.
1.Removethehairpincottersandremovethe2
pins(Figure11).
2.Lowertherollbartothedownposition(Figure
10).
Note:Thereare2downpositions;referto
Figure10.
3.Installthe2pinsandsecurethemwiththe
hairpincotters(Figure11).
g004954
Figure10
1.Full-downposition2.Downpositionwiththe
baggerinstalled
Important:Ensurethatyousecuretherear
partoftheseatwiththeseatlatch.
RaisingtheRollBar
Important:Alwaysusetheseatbeltwiththeroll
barintheraisedposition.
1.Removethehairpincottersandremovethe2
pins(Figure11).
2.Raisetherollbartotheuprightposition,install
the2pins,andsecurethemwiththehairpin
cotters(Figure11).
g004955
Figure11
1.Rollbar3.Pin
2.Raisedposition4.Hairpincotter
