Service Mode
Version Check Mode
1. Press "9" button twice on Remote Control during display of adjustment menu in the Service
Mode.
2. During Version Check, the following displays are shown.
ADJUSTMENT
Item Explanation/Data Format
1 MAIN MPU Target name of the microprocessor
2 EEPROM Version information of EEPROM : Display 1 byte data.
3 OPTION Option information : Display three numbers of 1 byte data.
4 BL ver Version information of Boot Loader software.
5 AP ver Version information of Application software.
6 A/D Adjust A/D adjustment status.
–COMP : Component input
–PC : PC input
–NTSC : NTSC (60Hz) SD signal (composite input).
–PAL : PAL (50Hz) SD signal (composite input)
OK : A/D adjustment set correctly.
NG : A/D adjustment set incorrect.
7 Model name Model name and Panel vendor
SA : SAMSUNG AU : AUO SH : SHARP LG : LGD CM : CMO
