Toshiba B-EV4 Series - When a Normal Printing Area Is 5.0 MM or Less

- 132 -
When a normal printing area is 5.0 mm or less:
[In the case a preceding normal printing area is merged.]
Because A is less than 5.0 mm, that area is merged into the duplicate printing area.
Label pitch (50.0mm)
Effective print length (48.0mm)
C=5.0mm
Effective
print width
(104.0mm)
A=3.0mm
B=Duplicate printing area (40.0mm)
Print direction
C=5.0mm
Effective
print width
(104.0mm)
A+B=Duplicate printing area (43.0mm)
Label pitch (50.0mm)
Effective print length (48.0mm)
Print direction
