Toshiba B-EV4 Series - In the Case a Subsequent Normal Printing Area Is Merged

- 133 -
[In the case a subsequent normal printing area is merged.]
Because C is less than 5.0 mm, that area is merged into the duplicate printing area.
C=3.0mm A=5.0mm
A=5.0mm
Effective
print width
(104.0mm)
B=Duplicate printing area (40.0mm)
Label pitch (50.0mm)
Effective print length (48.0mm)
Print direction
Effective
print width
(104.0mm)
B+C=Duplicate printing area (43.0mm)
Label pitch (50.0mm)
Effective print length (48.0mm)
Print direction
