7. PERIODIC MAINTENANCE PROCEDURE EO18-33027
7. PERIODIC MAINTENANCE PROCEDURE
7- 2
(4) Remove paper debris or label glue from the media path.
(5) When using the cutter unit, clean the cutter blade and the media path.
WARNING!
When cleaning the cutter, be careful not to be injured by the cutter blade.
1. Loosen the two Plastic Head Screws to remove the Cutter Cover.
2. Remove the jammed paper.
3. Clean the Cutter with a soft cloth slightly moistened with alcohol.
4. Attach the Cutter Cover.
Media Path
Cutter Unit
Plastic Head Screw
