Toshiba B-SA4T Series Product Description

2. SUPPLY SPECIFICATIONS EO10-33016A
(Revision Date: Feb. 14, 2008)
2.4 Specification of RFID Tag
2- 12
2.4.6 Printing on Bump (Chip/Antenna) Area
Embedding RFID tags in labels creates bumps in a chip/antenna area in the labels, causing incomplete
printing.
Especially, in the areas 5 mm from and left and right sides of the RFID-tag embedded area shown in the
figure below, uneven printing or incomplete printing can occur easily.
NOTE: The degree of poor printing quality differs depending on height of a chip/antenna used.
Media
feed
direction

RFID tag
embedded
area

Print quality on the
sides of RFID tag
is not guaranteed.
Print quality on
bumps is not
guaranteed.

Print quality on
bumps is not
guaranteed. 
Print quality on
the IC chip is not
guaranteed.

5mm
2.4.7 Ambient Temperature
Low temperature deteriorates wireless performance, under which conditions writing data on an RFID tag
may fail.
2.4.8 Strip Issue
Stripping performance in strip issue mode depends on the type of glue, tag, and backing paper. For some
RFID supplies used, an issue may not be performed properly in strip issue mode.
5mm

Toshiba B-SA4T Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Print Speed	Up to 152.4 mm/sec (6 ips)
Max Print Width	104 mm (4.09")
Resolution	300 dpi
Connectivity	USB 2.0
Optional Interfaces	Wireless LAN
Barcodes	UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, Industrial 2 of 5, Postnet, RM4SCC, KIX-Code
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code, Micro PDF417, Aztec Code
Media Thickness	0.06 – 0.19 mm
Media Roll Diameter	Max. 127 mm
Ribbon Length	Up to 300 m
Weight	15 kg
