Toshiba B-SX5T Series - Operation Panel; Interior

1. PRODUCT OVERVIEW ENGLISH VERSION EO1-33059
1.5 Appearance
E1- 4
1.5.4 Operation Panel
1.5.5 Interior
Please see Section 3.1 for further information about the Operation Panel.
LCD Message Display
ON LINE LED
(Green)
ERROR LED
(Red)
[PAUSE] key
POWER LED
(Green)
[FEED] key
[RESTART] ke
y
Ribbon Stoppe
r
Print Head Block
Head Lever
Ribbon Shaft
Supply Holde
r
Locking Ring
Supply Shaf
t
Print Head
Platen
Take-up Spool
