Toshiba CE-BCD308WE2-JT User Manual

Service Manual, 2017-8
26 / 51
1) Disassembly the back cover of air duct
2) Disassembly the foam of air duct
3) Open the air duct foam, remove the electric damper
8.5Evaporator and temperature sensing system
Evaporator in freezing chamber
1） Remove the air duct components in freezing
chamber.
2） Disconnect all connectors.
3） Remove the welding on inlet and outlet tubes.
4） Remove two screws which are used to fix the
evaporator and remove the evaporator.
Components on the evaporator
