Service Manual, 2017-8
28 / 51
Ambient temperature sensor
1） Remove refrigerated air duct back cover and foam
component
2） Remove chiller chamber sensor
Ambient temperature sensor
The sensor is located in the wire box of the refrigerator
top and sends temperature signal to microprocessor.As
the sensor connected to the main wire, if you need to
replace, you must cut the wire.
1）Disassembly air duct cover and foam
2）Disassembly freezer sensor
8.6Compressor case
Rear cover and compressor case
Piping system in the compressor case
