1.BEFORE USING FAX
1
1. DESCRIPTION OF EACH COMPONENT
Main Components
e-STUDIO3511/4511
1: Front cover 8: Inner tray
2: Drawers 9: Color toner (Cyan/Magenta/Yellow)
3: Operator’s manual pocket (back side) 10: Control panel
4: Power switch 11: Touch panel
5: Automatic duplexer 12: Touch panel contrast adjustment volume
6: Bypass tray 13: Black toner
7: Original scale 14: Used toner bag
*1: Large capacity feeder or Paper feed pedestal (optional)
*2: Reversing automatic document feeder
(optional: necessary equipment when the facsimile function is installed)
1
2
3
4
8
7
9
14
13
10
5
6
*1
*2
(
11
)
(
12
)
