Toshiba e-studio2330c Service Handbook

e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
SELF-DIAGNOSTIC MODE
2 - 116
Ozone filter-1 1198-0 to 8 1199 <Default values of code 1198
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0/0/0/0/
0
Sub-code 1: 40,000/46,000/56,000/
56,000/70,000/70,000/70,000
Sub-code 4: 170,000/170,000/170,000/
170,000/170,000/170,000/170,000
Developer material (K) 1200-0 to 8 1201 <Default values of code 1200
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0/0/0/0/
0
Sub-code 1: 40,000/46,000/56,000/
56,000/70,000/70,000/70,000
Sub-code 4: 125,000/125,000/125,000/
125,000/125,000/125,000/125,000
Developer material (Y) 1202-0 to 8 1203 <Default values of code 1202
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0/0/0/0/
0
Sub-code 1: 40,000/46,000/56,000/
56,000/70,000/70,000/70,000
Sub-code 4: 125,000/125,000/125,000/
125,000/125,000/125,000/125,000
Developer material (M) 1204-0 to 8 1205 <Default values of code 1204
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0/0/0/0/
0
Sub-code 1: 40,000/46,000/56,000/
56,000/70,000/70,000/70,000
Sub-code 4: 125,000/125,000/125,000/
125,000/125,000/125,000/125,000
Developer material (C) 1206-0 to 8 1207 <Default values of code 1206
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0/0/0/0/
0
Sub-code 1: 40,000/46,000/56,000/
56,000/70,000/70,000/70,000
Sub-code 4: 125,000/125,000/125,000/
125,000/125,000/125,000/125,000
Transfer (Wire/Roller/
1st transfer K roller)
1214-0 to 8 1215 <Default values of code 1214
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0/0/0/0/
0
Sub-code 1: 40,000/46,000/56,000/
56,000/70,000/70,000/70,000
Sub-code 4: 170,000/170,000/170,000/
170,000/170,000/170,000/170,000
Items
PM management
setting <Procedure
4> *Indicated in 8
digits
Date of previous
replacement
<Procedure 2>
Remarks
