e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
SELF-DIAGNOSTIC MODE
2 - 118
Pressure roller 1250-0 to 8 1251 <Default values of code 1250
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0/0/0/0/
0
Sub-code 1: 80,000/92,000/112,000/
112,000/140,000/140,000/140,000
Sub-code 4: 340,000/340,000/340,000/
340,000/340,000/340,000/340,000
Pressure roller
separation finger
1270-0 to 8 1271 <Default values of code 1270
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0/0/0/0/
0
Sub-code 1: 80,000/92,000/112,000/
112,000/140,000/140,000/140,000
Sub-code 4: 340,000/340,000/340,000/
340,000/340,000/340,000/340,000
Fuser belt 1272-0 to 8 1273 <Default values of code 1272
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0/0/0/0/
0
Sub-code 1: 80,000/92,000/112,000/
112,000/140,000/140,000/140,000
Sub-code 4: 340,000/340,000/340,000/
340,000/340,000/340,000/340,000
Fuser roller 1274-0 to 8 1275 <Default values of code 1274
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0/0/0/0/
0
Sub-code 1: 80,000/92,000/112,000/
112,000/140,000/140,000/140,000
Sub-code 4: 340,000/340,000/340,000/
340,000/340,000/340,000/340,000
Fuser belt guide 1276-0 to 8 1277 <Default values of code 1276
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0/0/0/0/
0
Sub-code 1: 80,000/92,000/112,000/
112,000/140,000/140,000/140,000
Sub-code 4: 340,000/340,000/340,000/
340,000/340,000/340,000/340,000
Pickup roller
(RADF)
1282-0, 1, 2, 8 1283 <Default values of code 1282
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 8: 0/0/0/0/0/0/0
Sub-code 1: 120,000/120,000/120,000/
120,000/120,000/120,000/120,000
Feed roller
(RADF)
1284-0,1,2,8 1285 <Default values of code 1284
(e-STUDIO2020C/2330C/2820C/2830C/
3520C/3530C/4520C)>
Sub-codes 0, 2, 8: 0/0/0/0/0/0/0
Sub-code 1: 120,000/120,000/120,000/
120,000/120,000/120,000/120,000
Items
PM management
setting <Procedure
4> *Indicated in 8
digits
Date of previous
replacement
<Procedure 2>
Remarks
