e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
ADJUSTMENT
3 - 18
[D] Secondary scanning data laser writing start position
Performing the code 05-408 covers this adjustment for all paper sources.
The adjustment for each paper source is also available.
For all paper sources
For each paper source
(1) While pressing [0] and [5] simultaneously, turn the power ON. → (Adjustment Mode)
(2) Press [98] ([3] for duplexing) → [FAX]. (A grid pattern with 10 mm squares is printed out.)
(3) Measure the distance D from the leading edge of the paper to the 6th line of the grid pattern.
* Normally, the 1st line of the grid pattern is not printed.
* At the duplexing, measure it on the top side of the grid pattern.
(4) Check if the distance D is within 52±0.5 mm.
(5) If not, use the following procedure to change values and measure the distance D again.
<Procedure>
(Adjustment Mode) → (Key in the code shown above) → [START]
→ (Key in an acceptable value shown above)
→ [ENTER] or [INTERRUPT] (Stored in memory)
→ “100% A” is displayed
→ Press [98] ([3] for duplexing)
→ [FAX] → (A grid pattern is printed out.)
* The larger the adjustment value is, the longer the distance D becomes (approx. 0.10 mm/
step).
Code Paper size Acceptable value Remarks
408 A3/LD 0 to 200 Performs the adjustment for all paper sources.
Order for
adjustment
Paper source Code Paper size
Acceptable
value
Remarks
1 1st drawer 440 A4/LT 0 to 100
2 2nd drawer 441 A3/LD 0 to 100
3 3rd drawer 444 A4/LT 0 to 100
4 4th drawer 428 A4/LT 0 to 100
5 Bypass feed 442 A4/LT 0 to 100
6 Duplexing 445 A3/LD 0 to 100 Paper fed from the 2nd drawer
