6
© 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C
ERROR CODE AND TROUBLESHOOTING
6 - 83
[CC61] Punch motor (M3) home position detection error
[CC71] Punch ROM checksum error
[CC72] Punch RAM read/write error
[CC80] Front jogging motor abnormality/Front aligning plate motor abnormality
* The [CC61] error will be displays when the [E9F0] error occurs three times in succession or
during the initial operation.
MJ-1101 (When MJ-6101 is installed)
Is there any paper remaining on the transport path?

YES Remove the paper.
NO
Rotate the punch motor (M3). Does it rotate smoothly?

NO Fix the mechanism.
YES
Are the punch home position sensor (S4) and its wiring correct?

NO Replace the sensor. Correct the wiring.
YES
Is the wiring between the hole punch control PC board (HP) and punch motor (M3) correct?

NO Correct the wiring.
YES
1. Replace the punch motor (M3).
2. Replace the hole punch control PC board (HP).
MJ-1101 (When MJ-6101 is installed)
Is the conductor pattern on the hole punch control PC board (HP) open circuited or short
circuited?

YES Replace the hole punch control PC board (HP).
NO
Replace the finisher control PC board.
MJ-1101 (When MJ-6101 is installed)
Is the conductor pattern on the hole punch control PC board (HP) open circuited or short
circuited?

YES Replace the hole punch control PC board (HP).
NO
Replace the finisher control PC board.
MJ-1030 (Front aligning plate motor abnormality)
Is the front aligning plate home position sensor (PI36) normal?
 NO  Replace the sensor.
YES
Is the wiring between the finisher controller PC board and the front aligning plate motor (M33)
correct?
 NO  Correct the wiring.
YES
Is there any mechanical problem with the path of aligning plate?
 NO  Fix the mechanism.
YES
1. Replace the front aligning plate motor.
2. Replace the finisher controller PC board.
To Next Page
