© 2005 - 2007 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO520/523/600/603/720/723/850/853
ADJUSTMENT
3 - 11
3
[C] Reproduction ratio of secondary scanning direction (Fine adjustment of transfer belt motor rotation
speed (Copier/Printer))
<Procedure>
(1) While pressing [0] and [5] simultaneously, turn the power ON. (Adjustment mode)
(2) Press [1] [FAX]. (A grid pattern with 10 mm squares is printed out. Use A3/LD in the 2nd/4th
drawer.
(3) Check the grid pattern on the test chart printed out and measure the distance C from the 6th line
at the leading edge of the paper to the 26th line of the grid pattern.
* Normally, the 1st line of the grid pattern is not printed.
(4) Check if the distance C is within 200±0.5 mm.
(5) If not, use the following procedure to change values and measure the distance C again.
(Adjustment Mode) (Key in code [488]) [START]
(Key in a value (acceptable values: 0 to 255))
[ENTER] or [INTERRUPT] (Stored in memory)
“100% A” is displayed
Press [1] [FAX] (A grid pattern is printed out.)
* The larger the adjustment value is, the longer the distance C becomes (approx. 0.2 mm/step).
[D] Secondary scanning data laser writing start position
This adjustment has to be performed for each paper source. (If there is no paper source, skip this step.)
The following table shows the order of the paper source to be adjusted, code, paper size and accept-
able values.
* Image location of all paper sources can be adjusted in the Adjustment mode (05-408)
For 4 drawers
Order for
adjustment
Paper source Code Paper size
Acceptable
value
Remarks
1 1st drawer 440 A4/LT 0 to 40
2 2nd drawer 441 A3/LT 0 to 40
3 3rd drawer 444 A4/LT 0 to 40
4 4th drawer 428 A4/LD 0 to 40
5 LCF 443 A4/LT 0 to 40
6 Bypass feed 442 A3/LD 0 to 40
7 Duplexing 445 A3/LD 0 to 40 Paper fed from the 2nd/4th drawer
- All 408 - 0 to 80
To Next Page
