8
© 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
ERROR CODE and TROUBLESHOOTING
8 - 149
[CC20] Communication error between finisher and saddle stitcher
[CC30] Stack transport motor abnormality
[CC31] Transport motor abnormality
Classification Error item
Finisher related service call Communication error between finisher controller PC board
and saddle stitcher controller board [MJ-1103/1104]
Check item Measures
Equipment • Is the problem solved by turning OFF and ON the power
switch of the equipment?
Finisher control PC board (FIN) • Connector check
• Board check
Saddle control PC board (SDL) • Connector check
• Board check
Replace parts Remarks
Finisher control PC board
Saddle control PC board
Classification Error item
Finisher related service call The stack transport motor is not rotating or the stack transport
belt is not moving normally. [MJ-1103/1104]
You receive a [CC30] error when the [EA70] error occurs
three times in succession.
Check item Measures
Stack transport belt • Is there any mechanical problem when the stack transport
belt is moved?
Stack transport motor (M5) • Motor check
• Connector check
• Harness check
Finisher control PC board (FIN) • Connector check (CN10)
• Board check
Replace parts Remarks
Stack transport motor
Finisher control PC board
Classification Error item
Finisher related service call The transport motor is not rotating or the stack transport roller
-1 and -2 is not rotating normally. [MJ-1103/1104]
You receive a [CC31] error when the [ED12] error occurs
three times in succession.
To Next Page
