Toshiba E-studio5540c Service Manual

e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 150
[CC41] Paper holder cam home position abnormality
[CC51] Sideways adjustment motor (M2) abnormality
Check item Measures
Stack transport roller-1/-2 • Is there any mechanical problem when the stack transport
roller -1 and -2 are rotated?
Transport motor (M2) • Motor check
• Connector check
• Harness check
Finisher control PC board (FIN) • Connector check (CN5)
• Board check
Replace parts Remarks
Transport motor
Finisher control PC board
Classification Error item
Finisher related service call The paper holder cam is not at the home position. [MJ-1103/
1104]
Check item Measures
Paper holder cam • Is there any mechanical problem when the paper holder
cam is rotated?
Paper holder home position sensor
(S6)
• Sensor check
• Connector check
• Harness check
Finisher control PC board (FIN) • Connector check (CN17)
• Board check
Replace parts Remarks
Paper holder home position sensor
Finisher control PC board
Classification Error item
Finisher related service call Sideways adjustment motor is not rotating or puncher is not
shifting normally. [MJ-6102]
The [CC51] error will be displays when the [ED11] error
occurs three times in succession or during the initial
operation.
Check item Measures
Sideways adjustment motor (M2) • Motor check
• Connector check
• Harness check
Sideways deviation home position
sensor (S3)
• Sensor check
• Connector check
• Harness check
