Toshiba E-studio5540c Service Manual

8
© 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
ERROR CODE and TROUBLESHOOTING
8 - 151
[CC52] Skew adjustment motor (M1) abnormality
[CC60] Punch motor abnormality
Hole punch control PC board (HP) • Connector check
• Board check
Replace parts Remarks
Sideways adjustment motor
Sideways deviation home position
sensor
Hole punch control PC board
Classification Error item
Finisher related service call Skew adjustment motor is not rotating or puncher is not
shifting normally. [MJ-6102]
The [CC52] error will be displays when the [ED10] error
occurs three times in succession or during the initial
operation.
Check item Measures
Skew adjustment motor (M1) • Motor check
• Connector check
• Harness check
Skew home position sensor (S2) • Sensor check
• Connector check
• Harness check
Hole punch control PC board (HP) • Connector check
• Board check
Replace parts Remarks
Skew adjustment motor
Skew home position sensor
Hole punch control PC board
Classification Error item
Finisher related service call Punch motor is not rotating or puncher is not shifting normally.
[MJ-6102]
Check item Measures
Punch home position sensor (PI63) • Sensor check
• Connector check
• Harness check
Punch motor clock sensor (PI62) • Sensor check
• Connector check
• Harness check
Punch motor (M3) • Motor check
• Connector check
• Harness check
Check item Measures
