Toshiba e-studio555 - Developer Unit Components

11
© 2009 - 2011 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO555/655/755/855
DEVELOPER UNIT
11 - 1
11. DEVELOPER UNIT
11.1 Construction
This chapter describes about the following units related to the development process, parts, control
circuit, etc.
• Toner cartridge drive unit
• Toner recycle unit
• Developer unit
- Developer material
- Mixer unit
- Paddle
- Transport sleeve (magnetic roller)
- Upper/Lower developer sleeve
- Doctor blade
- Auto-toner sensor
- Scattered toner recovery roller
• Developer unit drive section
Fig. 11-1
Auto-toner sensor
Paddle
Mixer unit
Doctor blade
Drum
Upper developer sleeve
Transport sleeve
Lower developer sleeve
Scattered toner recovery roller
