(iii) Setting bands for the operation
As illustrated in Figure 9.2-7, with regard to the entering current the user can define the upper
limit and lower limit using the setting [ISD] in %. The limit-size of the SD feature is calculated
based on the amount of the entering current. Table 9.2-4 shows respective settings for the
power quantities.
Table 9.2-4 SD settings for respective quantities
Quantities
SD settings
Units for
settings
Setting ranges
Voltage
VSD
%
0.00% to 50.00%
Current
ISD
%
0.00% to 50.00%
Active/Reactive/Apparent power
P/Q/SSD
–
0.00% to 50.00%
Power factor
PFSD
–
0.00 to 1.00
Frequencty
FSD
%
0.00% to 50.00%
Watt-hour/var-hour
Wh/varhSD
–
0.0 to 999.9
Phase
PhaseSD
Degree
0.0 deg. to 90 deg.
Difference of voltages†
dVSD
%
0.00% to 50.00%
†Note: The values are derived in the VCHK function. For more information, see Chapter
Relay application: Voltage check for autoreclose function .
Figure 9.2-8 Metering setting in the setting screen
Note: For the operation of the menu, see Chapter User interface: Setting sub-menu .
Metering
10:48 1/8
ISD +
5.00 %
VSD +
0.60 %
dVSD +
0.60 %
