6F2S1914 (0.49)
GRL200 (Soft 033 & 037)
- 1209 -
Measurand Data IDs
Measurand to be used in
Software 33(VCT11B)
Metering
values
Types of inputs
Unit
GR-TIEMS and
IEC103
IEC61850
Fault recording
Note
Idcpu
DIF-L Phase-C Idpu measurement secondary
A
7110014301BB1054
N/A
N/A
Ira
DIF-L Phase-A Ir measurement primary for fault record / metering
A
7110014301A81076
N/A
7110014301A81076
Ira
DIF-L Phase-A Ir measurement secondary for fault record / metering
A
7110014301A81050
N/A
7110014301A81050
Irb
DIF-L Phase-B Ir measurement primary for fault record / metering
A
7110014301A81078
N/A
7110014301A81078
Irb
DIF-L Phase-B Ir measurement secondary for fault record / metering
A
7110014301A81052
N/A
7110014301A81052
Irc
DIF-L Phase-C Ir measurement primary for fault record / metering
A
7110014301A8107A
N/A
7110014301A8107A
Irc
DIF-L Phase-C Ir measurement secondary for fault record / metering
A
7110014301A81054
N/A
7110014301A81054
Ir0
DIFG-L Ir0 measurement primary for fault record / metering
A
7110014301AA107C
N/A
7110014301AA107C
Ir0
DIFG-L Ir0 measurement secondary for fault record / metering
A
7110014301AA1056
N/A
7110014301AA1056
Id0pu
DIFG-L Id0pu measurement primary for fault record / metering
A
7110014301AB107C
N/A
7110014301AB107C
Id0pu
DIFG-L Id0pu measurement secondary for fault record / metering
A
7110014301AB1056
N/A
7110014301AB1056
I2/I1
I2/I1 measurement for fault record / metering
-
7110014300B51090
N/A
7110014300B51090
THM-Capacity
Percentage of thermal capacity for fault record / metering
%
7110014300A01090
N/A
7110014300A01090
df/dt
df/dt measurement
Hz/s
7110014300B61090
N/A
N/A
