Supervision tasks for device dependent features
Displaying errors regarding to special problems are summarized in Table 10.2-1; the error is
cleared when recovered
Table 10.5-1 Supervision items and error levels for device-dependent
Detailed
ERROR
Sec.
No.
Supervision items(Screen message)
Info.
LVL.
LED
10.5.1
Error detection of differential current in DIF (Id)
N/A
3
On
10.5.2
Current transformer failure detected with DIF (DIF-CT)
N/A
3
On
10.5.3
Synchronizing and sampling error (Com sync fail)
N/A
2
On
10.5.4
Communication failure (Com fail)
N/A
2
On
10.5.5
Error signal level for sending (TX level)
N/A
3
On
10.5.6
Error signal level for receiving (RX level)
N/A
3
On
10.5.7
Propagation delay error (Com Td)
Displayed
3
On
10.5.8
Error terminal configuration (Term ID)
N/A
2
On
10.5.9
Monitoring ready state at the remote (Term rdy)
N/A
2
On
10.5.10
Transmission error (Com fail-R)
N/A
2
On
10.5.11
Master-slave monitoring (MSCHK)
N/A
2
On
10.5.12
Supervision of Relay ID (RYID)
Displayed
2
On
─────────────────────────────────────────────────────────────────
Note: The implementation of particular features is dependent upon the selection of
hardware and the configuration of functions. Several IED models do not support certain
features. To determine whether a particular feature has been implemented within an IED,
identify the IED ordering number; and check the order number for the “G&T position” whilst
referring to the comparison table below. For more information, see Appendix: Ordering .
Table 10.5-2 Comparative table in respective ordering numbers
Sec.
Feature
Ordering No. at “G&T”
33
37
–
Device dependent supervision tasks
✓
✓
✓: Applicable NA: Not applicable
