10.5.12 Supervision of Relay ID (RYID)
When the IED is designated with relay addresses (relay ID), the relay ID can be monitored by
the communication application when the user set On for the settings [CHK_RYID:Sw]. For
more information with regard to the relay address, see chapter Relay application:
Communication application .
(i) Error level
Generally, the default error level is set at level 2 (Serious error (Comm)), but the user can
program the level using settings [CHK_RYID1:Lvl] and [CHK_RYID2:Lvl]; then, set On for the
settings [CHK_RYID1:Sw] and [CHK_RYID 2:Sw].
(ii) Error message
When the function operates and detects error, an error message can be shown at the LED and
the LCD screen.
Table 10.5-25 Error messages provided by the supervisor in CHK_RYID
Message and level
Meaning of the information
RYIDx error
Detection for erroneous Relay ID at x module
Error level
Serious error (Level 2)
Table 10.5-26 Detailed information in Hexadecimal in CHK_RYID
Display
area
Meaning of the detailed information
Left column
Right column
Top
row
Relay ID expecting
Relay ID received in practice
Middle
row
(No information is displayed)
(No information is displayed)
Bottom
row
(No information is displayed)
(No information is displayed)
