2.19.6 Data ID
◆ Signal monitoring point
BCD(Function ID: 452001)
Element ID
Name
Description
8000001C23
BCD
BCD relay element operated
8000001B60
BCD-OPT
BCD protection operated
8000001BB0
BCD_BLOCK
BCD protection block command
8300001B23
BCD-OPT-TRIP
Trip signal by BCD1 protection operation
8400001B62
BCD-OPT-ALARM
Alarm signal by BCD1 protection operation
◆ Connection point on PLC logic
BCD(Function ID: 452001)
Element ID
Name
Description
800000EBB0
BCD_BLOCK
BCD1 protection block command
