Signal Number
Signal Name
Description
M/O
513001 820402EE5E
TPOS02IN_TMP_38
TPOS02 operate condition configured by the user (for PLC#2)
O
513001 820403EE5E
TPOS03IN_TMP_38
TPOS03 operate condition configured by the user (for PLC#2)
O
…
…
…
513001 820418EE5E
TPOS24IN_TMP_38
TPOS24 operate condition configured by the user (for PLC#2)
O
Table 4.9-17 PLC connection points (Input signal PLC#3 user configurable condition)
Signal Number
Signal Name
Description
M/O
513001 810401EE57
TPOS01IN_TMP_28
TPOS01 operate condition configured by the user (for PLC#3)
O
513001 810402EE57
TPOS02IN_TMP_28
TPOS02 operate condition configured by the user (for PLC#3)
O
513001 810403EE57
TPOS03IN_TMP_28
TPOS03 operate condition configured by the user (for PLC#3)
O
….
….
…
513001 810418EE57
TPOS24IN_TMP_28
TPOS24 operate condition configured by the user (for PLC#3)
O
Table 4.9-18 PLC connection points (Input signal PLC#4 user configurable condition)
Signal Number
Signal Name
Description
M/O
513001 840401EE58
TPOS01IN_TMP_29
TPOS01 operate condition configured by the user (for PLC#4)
O
513001 840402EE58
TPOS02IN_TMP_29
TPOS02 operate condition configured by the user (for PLC#4)
O
513001 840403EE58
TPOS03IN_TMP_29
TPOS03 operate condition configured by the user (for PLC#4)
O
…
…
…
513001 840418EE58
TPOS24IN_TMP_29
TPOS24 operate condition configured by the user (for PLC#4)
O
Table 4.9-19 PLC connection points (Input point additional, user configurable condition)
Signal Number
Signal Name
Description
M/O
513001 800401EE65
TPOS01IN_TMP_33
Condition added by the user in TPOS01 (for PLC#1)
O
513001 800402EE65
TPOS02IN_TMP_33
Condition added by the user in TPOS02 (for PLC#1)
O
513001 800403EE65
TPOS03IN_TMP_33
Condition added by the user in TPOS03 (for PLC#1)
O
…
…
…
513001 800418EE65
TPOS24IN_TMP_33
Condition added by the user in TPOS24 (for PLC#1)
O
513001 810401EE66
TPOS01IN_TMP_34
Condition added by the user in TPOS01 (for PLC#2)
O
513001 810402EE66
TPOS02IN_TMP_34
Condition added by the user in TPOS02 (for PLC#2)
O
513001 810403EE66
TPOS03IN_TMP_34
Condition added by the user in TPOS03 (for PLC#2)
O
…
…
…
513001 810418EE66
TPOS24IN_TMP_34
Condition added by the user in TPOS24 (for PLC#2)
O
Table 4.9-20 PLC monitoring points (Output signal for BIO)
Signal Number
Signal Name
Description
513001 8104011DD0
TPOS01_P1EX_BO
Operate command (P1) for Binary Output in TPOS01
513001 8104021DD0
TPOS02_P1EX_BO
Operate command (P1) for Binary Output in TPOS02
513001 8104031DD0
TPOS03_P1EX_BO
Operate command (P1) for Binary Output in TPOS03
…
…
…
513001 8104181DD0
TPOS24_P1EX_BO
Operate command (P1) for Binary Output in TPOS24
513001 8204011DD3
TPOS01_P2EX_BO
Operate command (P2) for Binary Output in TPOS01
513001 8204021DD3
TPOS02_P2EX_BO
Operate command (P2) for Binary Output in TPOS02
513001 8204031DD3
TPOS03_P2EX_BO
Operate command (P2) for Binary Output in TPOS03
….
….
….
513001 8204181DD3
TPOS24_P2EX_BO
Operate command (P2) for Binary Output in TPOS24
513001 8204011DD6
TPOS01_P3EX_BO
Operate command (P3) for Binary Output in TPOS01
513001 8204021DD6
TPOS02_P3EX_BO
Operate command (P3) for Binary Output in TPOS02
513001 8204031DD6
TPOS03_P3EX_BO
Operate command (P3) for Binary Output in TPOS03
