– 199 –
Yes
No
Yes
No
[F03]
Yes
No
Yes
No
[F01]
Yes
No
Yes
No
[F02]
[F04]
[F05]
esuaCedoc kcehC Check code name
esuaCedoc kcehC Check code name
esuaCedoc kcehC Check code name
esuaCedoc k
ceh
C Check code name
esuaCedoc kcehC Check code name
Indoor TCJ sensor error
TCJ sensor Open/Short
Indoor TC1 sensor error
TC1 sensor Open/Short
TD1 sensor error
TD1 sensor Open/Short
TD2 sensor error
TD2 sensor Open/Short
[F06]
e
suaC
ed
o
c
k
cehC Check code name
TE1 sensor error
TE1 sensor Open/Short
Indoor TC2 sensor error
TC2 sensor Open/Short
Is TCJ
sensor connector
(CN102: Red) on indoor
P.C. board normally
connected?
Is TC1
sensor connector
(CN100: Brown) on indoor
P.C. board normally
connected?
Are characteristics
of TCJ sensor resistance
value normal?
Are characteristics
of TC1 sensor resistance
value normal?
Is TC2
sensor connector
(CN101: Black) on indoor
P.C. board normally
connected?
Are characteristics of
TC2 sensor resistance
value normal?
Correct connection of
connector.
Correct connection of
connector.
Replace TC1 sensor.
Replace TCJ sensor.
Correct connection of
connector.
Replace TC2 sensor.
Check indoor P.C. board.
Defect
Replace
Check indoor main P.C. board.
Defect
Replace
Check indoor P.C. board.
Defect
Replace
* See “Indoor unit temperature sensor characteristics” on “8-9. Sensor Characteristics”.
* See “Indoor unit temperature sensor characteristics” on “8-9. Sensor Characteristics”.
* See “Indoor unit temperature sensor characteristics” on “8-9. Sensor Characteristics”.
This error code means detection of Open/Short of TD1 sensor. Check disconnection of circuit for connection of
connector (TD1 sensor: CN502, White) and characteristics of sensor resistance value. (See “Outdoor unit temperature
sensor characteristics” on “8-9. Sensor Characteristics”.)
If sensor is normal, replace outdoor I/F P.C. board.
This error code means detection of Open/Short of TD2 sensor. Check disconnection of circuit for connection of
connector (TD2 sensor: CN503, Pink) and characteristics of sensor resistance value. (See “Outdoor unit temperature
sensor characteristics” on “8-9. Sensor Characteristics”.)
If sensor is normal, replace outdoor I/F P.C. board.
This error code means detection of Open/Short of TE1 sensor. Check disconnection of circuit for connection of
connector (TE1 sensor: CN505, Green) and characteristics of sensor resistance value. (See “Outdoor unit temperature
sensor characteristics” on “8-9. Sensor Characteristics”.)
If sensor is normal, replace outdoor I/F P.C. board.
To Next Page
