P9 ASD Installation and Operation Manual 245
Table 6. Discrete Input Terminal Assignment Selections and Descriptions.
*Sel. No.
Terminal Selection Descriptions
NO NC
01
Unassigned — No operation.
23Forward — Provides a Forward run command.
45Reverse — Provides a Reverse run command.
67Standby — Enables the Forward and Reverse operation commands.
89Reset — Resets the device and any active faults.
10 11 Preset Speed 1 — Preset Speed 1 is used as the LSB of the 4-bit nibble that is used to select a Preset Speed.
12 13 Preset Speed 2 — Preset Speed 2 is used as the second bit of the 4-bit nibble that is used to select a Preset Speed.
14 15 Preset Speed 3 — Preset Speed 3 is used as the third bit of the 4-bit nibble that is used to select a Preset Speed.
16 17 Preset Speed 4 — Preset Speed 4 is used as the MSB of the 4-bit nibble that is used to select a Preset Speed.
18 19
Jog — This terminal activates a Jog for the duration of the activation. The Jog settings may be configured at F260 –
F262.
20 21
Emergency Off — Terminates the output signal from the ASD and may apply a brake if so configured. The braking
method may be selected at F603.
22 23
DC Braking — The ASD outputs a DC current that is injected into the windings of the motor to quickly brake the
motor.
24 25
Accel/Decel Switching 1/Accel/Decel Switching 2 — Activating combinations of discrete input terminals
Accel/Decel Switching 1 and 2 allow for the selection of Accel/Decel profiles 1 – 4 as shown below.
See F504 for additional information on this terminal setting.
26 27
28 29
V/f Switching 1/V/f Switching 2 — Activating combinations of discrete input terminals V/f Switching 1 and 2
allow for the selection of a V/f switching
profile as listed below.
30 31
NO/NC = Normally Open/Normally Closed.
*Selection numbers are used when configuring the ASD via communications. The Normally Open (NO) or Normally
Closed (NC) configuration must be chosen by selecting the associated number.
A/D SW Terminal
A/D Profile Selection
#1 #2
00 1
01 2
10 3
11 4
1=Terminal Activated
The settings of the A/D selections 1 – 4 are performed
at F009/F010, F500/F501, F510/F511, and F514/
F515, respectively.
Accel/Decel profiles are comprised of the Accel/
Decel settings, Pattern, and Switching Frequency.
V/f Switching Terminal
V/f Selection
#1 #2
00 1
01 2
10 3
11 4
1=Terminal Activated
The 1 – 4 settings of the V/f Switching
selections are performed at F170 – F181.
