–8–
Concealed Duct High Static Pressure
Installation Manual
EN
External view (Unit:mm)
965
(50)
(50)
(50)
950
1050
704
600
664
(36)
(50)
(73.5)
52
32
30
11
12
(35)
(Hanging bolt pitch)
(Hanging bolt pitch)
Air inlet
port flange
(Procured
locally)
Flow direction of
the air
(Hanging bolt pitch)
Refrigerant pipe gas side connecting
external length
Drain pipe connecting pipe external length
Air outlet
port flange
(Procured
locally)
Refrigerant pipe liquid side connecting
external length
42
50
97
53
380
25
32
490
600
Refrigerant pipe gas side
connecting port (5/8" (Ø15.9))
Refrigerant pipe liquid side
connecting port (3/8" (Ø9.5))
Electric parts box (Cover is removable) Drain port (Vinyl chloride pipe VP25:Ø32)
8-EN
+00EH99860501_01EN_DuctHigh_IM.book Page 8 Monday, January 19, 2009 8:38 AM
