Toshiba SMMS-e Quick Reference Guide

DN Item Description At Shipment
01
Filter Display Delay Timer
0000: None 0001: 150H
According to Type
0002:
2500H 0003: 5000H
0004:
10000H
02
Dirty Filter State
0000: Standard
0000: Standard
0001:
High Degree of Dirt
03
Central Control Address
(Shown as Group # on
Central Control)
0000: No.1 Unit to 0064: No.64 Unit
0099: Unfixed
0099: Unfixed
04
Specific Indoor Unit
Priority
0000:
No
Priority
0001: Priority
0002:+2*C (3.6*F)
( Floor Type 0000: 0*C )
05
Fan Control Heating
0001: Default 0009: Fan Off Thermo Off
0001:
* Must have wired remote Change DN-32 to 0001 before use of DN-05
06
Heating SuctionTemp Shift
0000: No Shift 0001: +1*C (+1.8*F)
0002: +2*C (3.6*F)0002: + 2*C (+3.6F) to 0010: +10*C (+18*F)
( Up to +6 Recommended)
OC
Preparing Indication
Selection
0000: Preparing indicated 0001: No Indication 0000: Preparing indicated
0D
Existence of AUTO Mode
0000: Provided
0001: Not Provided
0001: Not Provided (Automatic selection from connected outdoor unit)
0E
FS Box 0000: Only 1 indoor unit on FS 0001: More than 1 indoor unit 0000: Standard
0F
Cooling Only
0000: Heat Pump
0000: Heat Pump
0001: Cooling Only (No Display of (AUTO) (HEAT) )
10
Unit Type
0001: 4-Way Air Discharge Cassette 0004: Standard Ducted
Depending on Model
0005: Slim Duct 0006: High Static Ducted
0007: Under Ceiling 0008: High Wall
0014: Compact 4 Way
11
Indoor Unit Capacity
0000: Unfixed 0001 to 0034
According to Capacity
See Page 50 SHRM Quick Reference
12
Line Address 0000: No.1 Unit to 0030: No. 30 Unit 0099: Unfixed
13
Indoor Unit Address 0001: No.1 Unit to 0064: No.64 Unit 0099: Unfixed
14
Group Address
0000: Individual 0001: Header in Group
0099: Unfixed
0002: Follower in Group
19
Louver Type
(Air direction adjustment)
0000: No louver 0001: Swing only
According to Type
0002: (1-Way Air discharge Cassette type, Under Ceiling type)
0003: (2-Way Air discharge Cassette type)
0004: (4-Way Air discharge Cassette type)
1E
Temp Range C/H
0000: 0 degree to 0010: 10 degree 0003: 3 Degree
(Dead Band Heat
Cool/Cool Heat)
(Cool / Heat are reversed with +/- (data value) / 2 against the set temperature)
Auto Switch Control Point ( Ts +/- 1.5 )
DN CODES
9
