1 Hardware Overview
1.4 2.5-inch Hard Disk Drive
The removable HDD is a random access non-volatile storage device. It has a non-removable
2.5-inch magnetic disk and mini-Winchester type magnetic heads.
The computer supports a 160GB, 250GB or 320GB.
The HDD is shown in figure 1-5. Specifications are listed in Table 1-2.
Figure 1-7 2.5-inch HDD
Table 1-2 2.5-inch HDD specifications
Specifications
Items
FUJITSU
G8BC00065160
FUJITSU
G8BC00065250
FUJITSU
G8BC00065320
Outline Width (mm)
100.0
Dimensio
ns
Height (mm)
9.5
Depth (mm)
70
Weight (g)
96 max 101 max
Storage size (formatted) 160GB 250GB 320GB
Speed (RPM) 5,400
Data transfer speed (Mb/s)
To/Form Media
To/Form Host
116.2 MB/s Max
150 MB/s (Genli)
Data buffer size (MB/s) 8
Positioning Time(read and
seek time)
Read: 12ms
Motor startup time (s) 4
TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784)[CONFIDENTIAL] 1-19

Toshiba TECRA A11 Series Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Professional
Battery Life	Up to 4 hours
Optical Drive	DVD SuperMulti Drive
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6-inch HD (1366x768)
Storage	HDD up to 500GB
Graphics	Intel HD Graphics
Wireless	802.11 a/g/n
Webcam	Integrated webcam
Ports	USB 2.0, VGA, RJ-45
Card Reader	SD
Battery	6-cell Li-ion
Dimensions	374 x 250 mm
Chipset	Mobile Intel QM57 Express Chipset
