4.29 Smart card unit 4 Replacement Procedures
TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] 4-85
Installing the Smart card unit
To install the Smart card unit, follow the steps below and refer to Figure 4-54.
1. Pass the Smart card FPC through the hole2 and slide the Smart card unit under the
guides until the hook is engaged.
2. Arrange the Smart card FPC while passing through the hole1.
3. Stick the insulator in place.
